Shanghai Shingmore bridge Imports&Exports co.,ltdAbout UsNO.28 TONGLIN ROAD,CHANGSHU CITY, JIANGSU PROVINCE, CHINA 215500Shanghai Shingmore Bridge Imports & Exports Co.,Ltd. Located in Shanghai,with very convenient transportation.We have many years experience in producing and exporting all kinds of buckets and other spare parts for excavator,wheel loader and other construction machinery.Our products are applicable to excavators (from 2tons to 100tons) of Komatsu Caterpillar Hitachi Doosan Kobelco Hyundai Volvo Sumitomo Kato Bobelco etc with hold capacity from 0.1cbm to 12cbm.Except the normal type products,we can also design the special products according to the customer's request.With our professional services and mature channels,

tree spade for loader
tree spade for loader
tree spade for loader
tree spade for loader
tree spade for loader
tree spade for loader
tree spade for loader

tree spade for loader

  • Minimum order quantity:1
  • Model NO.: TS
    • Applicable Industries:Building Material Shops
    • Applicable Industries:Machinery Repair Shops
    • Applicable Industries:Manufacturing Plant
    • Applicable Industries:Construction works
    • Place of Origin:CN;SHG
    • Warranty:1 YEAR
    • After-sales Service Provided:Field installation, commissioning and training
    • After-sales Service Provided:Video technical support
    • Brand Name:Shanghai SMB
    • landscape tree spade:landscape tree spade
    • landscape tree spade mode no.:BM10175
    • landscape tree spade overall length:3300mm
    • landscape tree spade overall width:3000mm
    • landscape tree spade height:3600mm
    • landscape tree spade digging depth:1421mm
    • landscape tree spade max gate opening:2100mm
    • landscape tree spade unit weight:3000kg
    • tree spade ball diam. available:0-1905mm
    • landscape tree spade origin:made in China
    China factory multifunction folded spade for municipal equipment on hot sale
    Product Description

    1. Tree spade model no.:BM0175

    2.Suitable for:skid steer loaders, wheel loaders, excavators

    3. Application: forest, farm, green industry

    4.Unitweight: about 3000kgs

    5.Our main markets are Ecuador, America, Panama,Russia,Australia,New zeland, Thailand, Singapore etc

    6. municipal equipment landscape tree spade capable 900mm root ball for sale made in China

    15series Tree Spade Specification

    Model No.

    050324

    050336

    050344

    BM0150

    BM0175

    Overall length A(mm)

    1320

    1991

    1974

    2250

    3300

    Overall width B(mm)

    1676

    2027

    1692

    2250

    3000

    Overall height C(mm)

    1320

    1491

    1994

    1550

    3600

    Digging depth D(mm)

    500

    747

    787

    1307

    1421

    Max gate opening(mm)

    80

    160

    240

    1930

    2100

    Blade angle( °)

    25

    25

    25

    25

    25

    Working flow(L/min)

    12-21

    12-21

    12-21

    100-300

    100-300

    Operating pressure(Mpa)

    16

    16

    16

    16-32

    16-32

    Fit tree diam.(mm)

    30-60

    50-100

    70-120

    160-220

    200-300

    Ball diam. available(mm)

    0-600

    0-900

    0-1100

    0-1300

    0-1905

    Weight(kg)

    545

    816

    981

    1000

    3000

    15 series tree spade specification

    0503 series 15 series tree spade-19

    0503 series 15 series tree spade-7

    0503 series 15 series tree spade-31

    0503 series 15 series tree spade-28

    0503 series 15 series tree spade-29

    Company Information

    13

    Main Products

    2the production line

    Packaging & Shipping

    1. standard packaging for landscape tree spade;
    2. customized package for landscape tree spade.
